Displaying Bsr Data; Displaying Bsr Status And Configuration - HP ProCurve 6200yl Multicast And Routing Manual

ProCurve(config)# show ip pim bsr
Status and Counters - PIM-SM Bootstrap Router Information
Elected BSR for
the PIM-SM
Domain
Candidate-BSR
Configuration for
the Current
Routing Switch
Candidate-RP
Configuration for
the Current
Routing Switch
Multicast
Groups for which
the Current
Routing Switch
Is Configured as
a Candidate-RP
Figure 4-20. Example of Listing BSR Data for the Domain and the Immediate Router

Displaying BSR Data

The router provides BSR information through both IP PIM and the running
configuration.

Displaying BSR Status and Configuration

Syntax: show ip pim bsr
Lists the identity, configuration, and time data of the
currently elected BSR for the domain, plus the BSR-candidate
configuration, the Candidate-RP configuration and the
supported multicast groups on the current router.
E-BSR Address
E-BSR Priority
E-BSR Hash Mask Length : 30
E-BSR Up Time
Next Bootstrap Message : 88 secs
C-BSR Admin Status
C-BSR Address
C-BSR Priority
C-BSR Hash Mask Length : 30
C-BSR Message Interval : 60
C-BSR Source IP VLAN
C-RP Admin Status
C-RP Address
C-RP Hold Time
C-RP Advertise Period
C-RP Priority
C-RP Source IP VLAN
Group Address Group Mask
--------------- ---------------
224.0.0.0 240.0.0.0
229.0.1.0 255.255.255.0
239.100.128.0 255.255.128.0
Displaying PIM-SM Data and Configuration Settings
: 10.10.10.2
: 0
: 53 mins
: This system is a Candidate-BSR
: 10.10.10.1
: 0
: 100
: This system is a Candidate-RP
: 10.10.10.1
: 150
: 60
: 192
: 100
