GS3700/XGS3700 Series

GbE L2+ Switch

Version 4.10

Edition 3, 06/2014

Quick Start Guide

User's Guide

Default Login Details

IP Address

http://192.168.0.1 (Out-

http://192.168.1.1 (In-

www.zyxel.com

User Name

Password

of-band MGMT port)

band ports)

admin

1234

Copyright © 2014 ZyXEL Communications Corporation

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the GS3700 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ZyXEL Communications GS3700 Series

Page 1 GS3700/XGS3700 Series GbE L2+ Switch Version 4.10 Edition 3, 06/2014 Quick Start Guide User’s Guide Default Login Details IP Address http://192.168.0.1 (Out- of-band MGMT port) http://192.168.1.1 (In- www.zyxel.com band ports) User Name admin Password 1234 Copyright © 2014 ZyXEL Communications Corporation...
Page 2 IMPORTANT! READ CAREFULLY BEFORE USE. KEEP THIS GUIDE FOR FUTURE REFERENCE. Note: This guide is a reference for a series of products. Therefore some features or options in this guide may not be available in your product. Screenshots and graphics in this book may differ slightly from your product due to differences in your product firmware or your computer operating system.
Page 3: Table Of Contents
Contents Overview Contents Overview User’s Guide ............................18 Getting to Know Your Switch ........................19 Hardware Installation and Connection ....................24 Hardware Overview ..........................28 The Web Configurator ..........................35 Technical Reference ..........................44 ZON Utility, ZON Neighbor Management and Port Status ..............45 Basic Setting ............................52 VLAN ...............................81 Static MAC Forward Setup ........................99 Static Multicast Forward Setup ......................101...
Page 4 Contents Overview Policy Routing ............................301 Differentiated Services ..........................305 DHCP ..............................313 VRRP ..............................327 Load Sharing ............................336 ARP Setup ............................338 Maintenance ............................344 Access Control ............................352 Diagnostic .............................373 Syslog ..............................375 Cluster Management ..........................378 MAC Table .............................384 IP Table ..............................387 ARP Table .............................389 Routing Table ............................391 Path MTU Table ............................392 Configure Clone ............................393 Neighbor Table ............................395...
Page 5: Table Of Contents
Table of Contents Table of Contents Contents Overview ..........................3 Table of Contents ..........................5 Part I: User’s Guide ..................18 Chapter 1 Getting to Know Your Switch......................19 1.1 Introduction ............................19 1.1.1 Bridging Example ........................20 1.1.2 High Performance Switching Example ..................20 1.1.3 Gigabit Ethernet to the Desktop ....................21 1.1.4 IEEE 802.1Q VLAN Application Example ................21 1.1.5 IPv6 Support ..........................22 1.2 Ways to Manage the Switch ......................22...
Page 6 Table of Contents Chapter 4 The Web Configurator ........................35 4.1 Introduction ............................35 4.2 System Login ..........................35 4.3 The Web Configurator Layout ......................36 4.3.1 Change Your Password ......................41 4.4 Saving Your Configuration ........................41 4.5 Switch Lockout ..........................41 4.6 Resetting the Switch ........................42 4.6.1 Reload the Configuration File ....................42 4.7 Logging Out of the Web Configurator ....................43...
Page 7 Table of Contents 6.9.6 IPv6 Global Address Setup .....................73 6.9.7 IPv6 Neighbor Discovery Setup ....................74 6.9.8 IPv6 Router Discovery Setup ....................75 6.9.9 IPv6 Prefix Setup ........................77 6.9.10 IPv6 Neighbor Setup ......................78 6.9.11 DHCPv6 Client Setup ......................79 Chapter 7 VLAN ..............................81 7.1 Introduction to IEEE 802.1Q Tagged VLANs ................81 7.1.1 Forwarding Tagged and Untagged Frames ................81...
Page 8 Table of Contents 11.1 STP/RSTP Overview ........................106 11.1.1 STP Terminology .........................106 11.1.2 How STP Works ........................107 11.1.3 STP Port States ........................107 11.1.4 Multiple RSTP ........................107 11.1.5 Multiple STP .........................108 11.2 Spanning Tree Protocol Status Screen ..................110 11.3 Spanning Tree Configuration ......................111 11.4 Configure Rapid Spanning Tree Protocol ...................
Page 9 Table of Contents 15.6 Static Trunking Example .......................143 Chapter 16 Port Authentication ..........................145 16.1 Port Authentication Overview .......................145 16.1.1 IEEE 802.1x Authentication ....................145 16.1.2 MAC Authentication ......................146 16.2 Port Authentication Configuration ....................147 16.2.1 Activate IEEE 802.1x Security ..................147 16.2.2 Guest VLAN ........................149 16.2.3 Activate MAC Authentication ....................151 Chapter 17 Port Security .............................153...
Page 10 Table of Contents 21.1 VLAN Stacking Overview ......................170 21.1.1 VLAN Stacking Example ......................170 21.2 VLAN Stacking Port Roles ......................171 21.3 VLAN Tag Format ..........................171 21.3.1 Frame Format ........................172 21.4 Configuring VLAN Stacking ......................172 21.4.1 Port-based Q-in-Q .......................174 21.4.2 Selective Q-in-Q .........................174 Chapter 22 Multicast ............................177 22.1 Multicast Overview ........................177...
Page 11 Table of Contents 23.2.1 RADIUS Server Setup .......................201 23.2.2 TACACS+ Server Setup ....................203 23.2.3 AAA Setup ...........................205 23.2.4 Vendor Specific Attribute .....................208 23.2.5 Tunnel Protocol Attribute .....................209 23.3 Supported RADIUS Attributes .......................209 23.3.1 Attributes Used for Authentication ..................210 23.3.2 Attributes Used for Accounting ....................210 Chapter 24 IP Source Guard..........................213 24.1 IP Source Guard Overview ......................213...
Page 12 Table of Contents 27.1.1 Layer-2 Protocol Tunneling Mode ..................242 27.2 Configuring Layer 2 Protocol Tunneling ..................242 Chapter 28 sFlow..............................245 28.1 sFlow Overview ..........................245 28.2 sFlow Port Configuration .......................245 28.2.1 sFlow Collector Configuration ....................247 Chapter 29 PPPoE ..............................249 29.1 PPPoE Intermediate Agent Overview ..................249 29.1.1 PPPoE Intermediate Agent Tag Format ................249 29.1.2 Sub-Option Format ......................249 29.1.3 Port State ..........................250...
Page 13 Table of Contents 33.1 Green Ethernet Overview ......................269 33.2 Configuring Green Ethernet ......................269 Chapter 34 Link Layer Discovery Protocol (LLDP) ...................271 34.1 LLDP Overview ..........................271 34.2 LLDP-MED Overview ........................272 34.3 LLDP Screens ..........................273 34.4 LLDP Local Status ........................274 34.4.1 LLDP Local Port Status Detail ....................276 34.5 LLDP Remote Status ........................280 34.5.1 LLDP Remote Port Status Detail ..................281 34.6 LLDP Configuration ........................287...
Page 14 Table of Contents 37.3.2 DSCP Profile ........................310 37.4 DSCP-to-IEEE 802.1p Priority Settings ................... 311 37.4.1 Configuring DSCP Settings ....................311 Chapter 38 DHCP..............................313 38.1 DHCP Overview ...........................313 38.1.1 DHCP Modes ........................313 38.1.2 DHCP Configuration Options ....................313 38.2 DHCP Configuration ........................313 38.3 DHCPv4 Status ..........................314 38.3.1 DHCPv4 Server Status Detail .....................314 38.4 DHCPv4 Relay ..........................315...
Page 15 Table of Contents 41.1 ARP Overview ..........................338 41.1.1 How ARP Works ........................338 41.1.2 ARP Learning Mode ......................338 41.2 ARP Setup ............................340 41.2.1 ARP Learning ........................340 41.2.2 Static ARP ...........................342 Chapter 42 Maintenance ............................344 42.1 The Maintenance Screen ......................344 42.2 Load Factory Default ........................345 42.3 Save Configuration ........................345 42.4 Reboot System ..........................346 42.5 Firmware Upgrade ........................346...
Page 16 Table of Contents 43.9.2 Mozilla Firefox Warning Messages ..................368 43.9.3 The Main Screen .........................370 43.10 Service Access Control ......................370 43.11 Remote Management ......................371 Chapter 44 Diagnostic ............................373 44.1 Diagnostic ............................373 Chapter 45 Syslog ..............................375 45.1 Syslog Overview ...........................375 45.2 Syslog Setup ..........................375 45.3 Syslog Server Setup ........................376 Chapter 46 Cluster Management ........................378...
Page 17 Table of Contents Chapter 51 Path MTU Table ..........................392 51.1 Path MTU Overview ........................392 51.2 Viewing the Path MTU Table ......................392 Chapter 52 Configure Clone..........................393 52.1 Configure Clone ...........................393 Chapter 53 Neighbor Table ..........................395 53.1 IPv6 Neighbor Table Overview .....................395 53.2 Viewing the IPv6 Neighbor Table ....................395 Chapter 54 Troubleshooting..........................397...
Page 18: User's Guide
User’s Guide...
Page 19: Getting To Know Your Switch
H A PT ER Getting to Know Your Switch This chapter introduces the main features and applications of the Switch. 1.1 Introduction Your Switch is a layer 2+, Gigabit Ethernet (GbE) switch with two power slots for hot-swappable RPS300 or RPS600-HP power modules. The Switch provides four SFP or SFP+ slots for uplink. By integrating router functions, the Switch performs wire-speed layer-3 routing in addition to layer-2 switching.
