Data Bit 8
•
Enable (default). The PI line is not passed directly from host to printer; all
8 bits are used for data bits, and characters in the hex 80-FF range can
be accessed.
•
Disable. When the host PI line is enabled, Data Bit 8 internally indicates
PI line status. To use the PI line, disable Data Bit 8, and enable the Host
PI configuration option (under the PI Control option, below).
NOTE: Data Bit 8 is interpreted as either Data Bit 8 or PI signal, but never
both. When enabled as Data Bit 8, Data Bit 8 has priority over the PI
signal, and all data above hex 7F is used to access character data
and not to interpret PI line data.
Conversely, when Data Bit 8 is disabled and the PI signal is used,
Data Bit 8 of the data is reserved for use as the PI function, and you
cannot access characters in the hex 80-FF range. Therefore, to
access characters in the hex 80-FF range, Data Bit 8 must be
enabled.
Font Set
The Font Set specifies which language is currently selected for use with the
ΙΓΠ/ςΓΛ Φοντ Σετ Μενυ ον παγε 207
VGL. Refer to
selections.
PI Control
Printer PI
•
Disable (default). The ASCII emulation is configured with the PI line
disabled.
•
Enable. The ASCII emulation is configured with the PI line enabled.
Host PI
•
Disable (default). The host does not send PI signals.
•
Enable. The host sends PI signals. The Data Bit 8 configuration option
must be disabled to transmit the PI line to the printer.
Max PI 16
•
Enable (default). A paper slew of 0-15 will move 1-16 lines.
•
Disable. A paper slew of 1-15 will move 1-15 lines. A paper slew of 0 will
always move 1 line.
for available
