Set The Tear Bar Distance

To set the tear bar distance, do the following steps:
1. Make sure the printer is offline.
2. Press ENTER key to enter the menu.
3. Press the right arrow
4. Press the down arrow
5. Press the right arrow
6. Press the down arrow
7. Press the left arrow
bar distance in increments of 1/144th of an inch.
8. Press ENTER to select the desired value. An asterisk appears next the
selected value and a scale prints to indicate the tear bar distance in
relation to the tear bar. For correct tear bar distance, the zero should align
with the tear bar. See Figure 34.
+50
-50
Print Station
Figure 34. Correct Tear Bar Distance
NOTE: When a new ZTP Tear Bar Dist value is selected, the printer will lose
the current print position until you reset the top of form to
automatically save the new value.
9. Reset the top of form using the procedure on page 304.
Set The Tear Bar Distance
until "OFFLINE/ZTP Menu" displays.
. "ZTP Data Time" displays.
until "ZTP TearDistance" displays.
. "ZTP TearDistance/xx/144 Inch" displays.
or right arrow to decrease or increase the tear
Physical TearBar
0
Position
Correct
TearBar
Distance
