Quiet/ID-MR
➥ Push to quet functon ON or OFF (CB channel operaton
only).
➥ Push and hold for 2 sec. to enter the receved ID code hs-
tory ndcaton mode.
SQL/ATS
➥ Push to enter the squelch level settng mode, then push
[CH Up] or [CH Down] to set the squelch level.
➥ Push and hold for 2 sec. to turn the ATS (Automatc Tran-
sponder System) functon ON and OFF.
Dup/Zone
➥ Push to set the selected channel as Duplex or Smplex
operaton.
• Duplex channel can be selected n 'CB-R1' to 'CB-R8' only.
➥ Push and hold ths key for 2 sec. then push [CH Up] or
[CH Down] to select the desred zone. (Avalable only
when more than two zones are set.)
Function/Set Mode
(Ths key functon can be assgned to the [Top] key only.)
➥ Push to turn Functon mode ON or OFF.
➥ Push and hold for 2 sec. to the Set mode ON or OFF.
• After enterng the Set mode, push ths key momentarly to select
the tem, and push [CH Up] or [CH Down] to change the settng.

PANEL DESCRIPTION

Function/RX VFO
(Ths key functon can be assgned to the [Top] key only.)
➥ Push to turn Functon mode ON or OFF.
➥ Push and hold for 2 sec. to enter the RX VFO mode.
In RX VFO mode, the operatng frequency and the chan-
nel spacng settng can be changed.
SQL/Set Mode
(Ths key functon can be assgned to the [Top] key only.)
➥ Push to enter the squelch level settng mode, then push
[CH Up] or [CH Down] to set the squelch level.
➥ Push and hold for 2 sec. to the Set mode ON or OFF.
• After enterng the Set mode, push ths key momentarly to select
the tem, and push [CH Up] or [CH Down] to change the settng.
