Icom IC-41S Instruction Manual page 46

10
BATTERY CHARGING
ï Rapid charging with the BC-119N+AD-106
The optonal BC-119N provdes rapd chargng of battery
packs. The followng tems are addtonally requred.
• AD-106 charger adapter
• An AC adapter or the DC power cable (OPC-515L/CP-23L).
• Charging period: Approx. 3 hours (wth BP-232N)
AC adapter
Optional OPC-515L
(for 13.8 V power
source) or CP-23L
(for 12 V cigarette
lighter socket) can
be used instead of
the AC adapter.
42
Turn power OFF
Transceiver
Battery pack
AD-106 charger
adapter is installed
in BC-119N.
IMPORTANT!:
Ensure the guide tabs
on the battery pack are
correctly aligned with
the guide rails inside
the charger adapter.
ï Rapid charging with the BC-121N+AD-106
The optonal BC-121N allows up to 6 battery packs to be
charged smultaneously. The followng tems are addtonally
requred.
• Sx AD-106 charger adapters
• An AC adapter (BC-157S) or the DC power cable (OPC-656)
• Charging period: Approx. 3 hours (wth BP-232N)
AC adapter
(Purchased
separately)
Tabs
DC power cable
(OPC-656)
(Connect with the
DC power supply;
Guide rails
13.8 V/at least 7 A)
Turn power OFF
Transceiver
Battery pack
AD-106 charger
adapters are
installed in each
IMPORTANT!:
Ensure the guide tabs
on the battery pack are
correctly aligned with
the guide rails inside
the charger adapter.
Guide rails
Tabs
