Record The Features And Options - Comtech EF Data DMD-2050E Installation And Operation Manual

DMD2050E Universal Satellite Modem
B.3.1

Record the Features and Options

Find and record the features and options that you want to add to the unit.
1. Go to the MAIN Menu.
2. Go to the SYSTEM Menu.
3. Go to the HW/FW CONFIG Menu.
4. Go to the FEATURES Menu. The lower line shows NORMAL.
5. Go to the UPGRADE LIST Menu.
6. Scroll through the list of features and options.
7. Record the items you want to upgrade.
Option Status Description
INSTALLED The option is already available in the feature set of the unit.
HW & KEY REQ The option is not installed and requires additional hardware. Contact Comtech for help.
HW REQUIRED The option requires additional hardware. Contact Comtech for help.
KEY CODE REQ The option is available as an upgrade that you install using the front panel.
MN-DMD2050E Revision 2
The Option is on the top line.
The Status is on the bottom line.
Front Panel Upgrade Procedure
B–2
