DMD2050E Universal Satellite Modem
4.4.3.1.1 DROP & INSERT (menu)
DROP & INSERT MENU
DROP MODE {NONE, T1-D4,
T1-ESF, PCM-30,
PCM-30C, PCM-31,
PCM-31C, T1-D4-S,
T1-ESF-S.}
MAP COPY {SRC Map to Dest
Map}
SAT CH TERRCH
4.4.3.1.2

TX ASYNC MODE (menu)

TX ASYNC MODE MENU
TX ASYNC MODE {ES-ES, ESC
ENHANCED}
ES INTERFACE {RS-232, RS-485}
ES BAUDRATE {150 – 1024}
For IBS ES to ES
{150 – 19200}
For ES to ES
Enhanced
{150 – 115200}
For SCC
Communications
ES BITS/CHAR {7, 8}
MN-DMD2050E Revision 2
Select any mode from the list.
Copy drop and insert maps. Tx ACT map is the drop map currently
being used by the modem. Source and destination may be any of the
following: TX ACT, RX ACT, TX EDIT, RX EDIT, USER 1 - USER 8,
ROM 1 -ROM 8
Edit the Tx edit map to specify the terrestrial slots that will be dropped
into assigned satellite channels. The satellite channels are fixed and the
number of channels is determined by the data rate. The terrestrial time
slots available are determined by the drop mode. The finished Tx edit
map is copied to the Tx ACT map before it is used by the modem.
ES-ES is the normal IBS Async Channel. ESC Enhanced can be
selected in Closed Net and uses the Overhead Signaling bytes in the IBS
Overhead to pass asynchronous data. This menu is not available when
SCC is selected.
Select the interface type.
ES to ES: Fixed Baud Rate based on IBS Network Specification. See
Table 3-3.
ES to ES Enhanced: Select the Interface Baud Rate. See Table 3-3.
SCC: Select the interface Baud rate. Interface Rate must be equal to or
greater than the In-Band Rate.
Choose either 7 or 8 bit data.
User Interfaces
4–21
