Chapter 3. Theory of Operation

3.1

DMD2050E Hardware

The DMD2050E is based on a two printed circuit card (minimum configuration) design with
additional optioned printed circuit cards available for additional features. The minimum
configuration consists of an L-Band/IF Assembly and a Digital Baseband Assembly. The optional
printed circuit cards include a Turbo Codec printed circuit card and one of several types of
Interface printed circuit card (refer to Appendix A). A block diagram of the DMD2050E is shown
in Figure 3-1.

Figure 3-1. DMD2050E Block Diagram

MN-DMD2050E Revision 2 3–1
