4.4.1.7

LOCAL AUPC (menu)

NOTE
When modems are configured for Radyne AUPC, the remote Eb/No is displayed in the Monitor
Menus.
LOCAL AUPC MENU
AUPC MODE
NOMINAL TX POWER
MN-DMD2050E Revision 2
{DISABLED, NEAR SIDE,
RADYNE, EFDATA}
{0 TO -45 dB}
DISABLED: Enable or disable the Local AUPC Function of
the local modem.
EBEM: Enables EBEM Local AUPC Function. In the event
the remote demodulator losses lock, the local output power
level will adjust itself to the nominal level. This nominal
power should be set to a level high enough to re-establish
communications regardless of rain fade.
EFDATA: Enables EFDATA Local AUPC Function. In the
event that the remote or local demodulator losses lock, the
output power level will adjust itself to the level settings
indicated in the 'REMOTE CL ACTION' Menu or the 'LOCAL
CL ACTION'.
RADYNE: Enables Radyne Local AUPC Function. In the
event the remote demodulator losses lock, the local output
power level will adjust itself to the nominal level. This
nominal power should be set to a level high enough to re-
establish communications regardless of rain fade.
NEAR SIDE: Enables NEARSIDE Local AUPC function. In
the event the local demodulator losses lock due to signal loss,
the output power level will adjust itself to the nominal level.
This nominal power should be set to a level high enough to
re-establish communications regardless of rain fade.
Set the nominal Transmit Power. The nominal transmit power
is the default output power level.
