H.1

Configuring the modem to use the Ethernet Data Interface (Optional)

When the optional Ethernet Data Interface Card is installed, all of the Ethernet related menus
become available and can be used to control the interface as follows:
Under the Interface Menu:
Under the Tx Setup Menu:
Set the Tx Clock Polarity to Normal.
Under the Interface Menu:
Under the Rx Setup Menu:
MN-DMD2050E Revision 2
Appendix H. Ethernet Data
Set the Terrestrial Interface to Ethernet.
Set the Ethernet Flow Control as desired.
Set the Ethernet Daisy Chain as desired.
Set the Ethernet QOS Type as desired.
Set the Ethernet QOS Queue as desired.
Set the Tx Clock to SCTE.
Set the Terrestrial Interface to Ethernet.
Set the Buffer Size to Zero.
Set the Buffer Clock to Rx Sat.
Set the Buffer Clock Polarity to Normal.
Interface Setup
