DMD2050E Universal Satellite Modem
I.2 Sample Applications
The following section provides brief application notes for operating the modem and explains by
example how to configure the modem for some of the most popular configurations.
The following information illustrates the allowable combinations for Mode and Data Rate.
Allowable Combinations: Mode/Rate/Framing.
IDR:
8.448 Mbps
6.312 Mbps
2.048 Mbps
1.544 Mbps or Below
IBS:
2.048 Mbps or below
Closed Network:
8.448:
6.312:
2.048:
1.544:
Any Rate 2.048 & lower:
MN-DMD2050E Revision 2
3/4, 7/8 Rate FEC
1/2, 3/4, 7/8 Rate FEC
1/2, 3/4, 7/8 Rate FEC
1/2, 3/4, 7/8 Rate FEC
1/2, 3/4, 7/8 Rate
96 Kb Framing or No Framing, 3/4, 7/8 Rate FEC
96 Kb Framing or No Framing, 1/2, 3/4, 7/8 Rate FEC
96 Kb Framing or 1/15 Framing or No Framing, 1/2, 3/4, 7/8 Rate FEC
96 Kb Framing or 1/15 Framing or No Framing, 1/2, 3/4, 7/8 Rate FEC
1/15 Framing or No Framing, 1/2, 3/4, 7/8 Rate FEC
Strap Codes
I–6
