User Interfaces
The DMD2050E has three interfaces available for typical operations:
Front Panel
•
Remote Port
•
Terminal
•
4.2
Front Panel Interface
Figure 4-1 shows the front panel. Table 4-1 describes each of the functional areas:
Vacuum Fluorescent Display (VFD)
•
Arrow Keys
•
Numeric Keys
•
LED Lights
•
VFD
MN-DMD2050E Revision 2
Chapter 4. User Interfaces
Arrow Keys
Figure 4-1. Front Panel
Numeric Keys
LED Lights
4–1
