DMD2050E Universal Satellite Modem
2.3.1

Location

The unit is intended for indoor use only. Do not install the unit in an unprotected outdoor location.
Direct contact with rain, snow, wind or sun causes damage to the unit.
Do not put units above high heat or an EMF generator. High heat and EMF have an unwanted
effect on output signals and receive operations.
Install the unit into any standard 19-inch equipment cabinet or rack. The unit is a one rack unit
(RU) (1.75 inches) high and 19 inches deep. It requires a minimum rack depth of 22 inches for
cables. If necessary, put the unit on a table or other suitable surface.
When viewed from the rear of the unit, the rear panel lets power enter from the left and IF cables
enter from the right. Data and control cables enter from either side, depending on installed
options.
You can stack up to a maximum of ten units. Make sure there is a minimum of one RU of empty
space for every ten stacked units. The empty space lets air flow in the rack.
2.3.2

Airflow

Make sure the unit has adequate airflow and the airflow is clean and relatively dry.
2.3.3

Temperature

The ambient temperature in the rack must be in the range of 10° and 35° C. The unit operates
best in constant temperature.
2.3.4

Electrical Power

The power supply is intended for universal application. The power supply specifications are 100
to 240 VAC, 50 to 60 Hz, 1.0A.
NOTE
If necessary for installing the unit correctly in your location, replace the power cable or
power connector with applicable parts.
MN-DMD2050E Revision 2
Installation
2–3
