The sequence is as follows:
1. Type 2 (PROC_APP) = Control processor firmware (cp.bin)
2. Type 1 (DSP_APP) = DSP firmware, use one of the following DSP
firmware files:
bostvb.dll
dsp1000.hex
dsp1000_ld.hex
dsp1000_ud.hex
dsp1 000_v34.hex
dsp1034_ud.hex
For example:
firm -m 2 -c 30 -t 2 cp.bin
firm -m 2 -t 1 dsp1000.hex
It takes about 10 seconds per module for the firmware to download
and for the module to begin operating. Proper operation is indicated
by the module status LED slowly flashing green.
See the descriptions of these programs in the Dialogic® Brooktrout®
Fax Products SDK Developer Guide chapter about sample
applications and utilities.
When the firmware is downloaded to a module for the first time, the
assigned ordinal channel numbers start wherever the assignment
left off on the previous module. As the system initializes the
modules, this numbering process creates a continuous ordering of
the channel assignments across all the modules in the system. On
later downloads, each module's ordinals begin at the same location,
regardless of any decrease or increase in the channel count of a
lower-numbered module. Therefore, if you decrease the channel
count for a lower numbered module, the process creates gaps in the
channel numbering assignments, possibly affecting your application.
If you attempt to increase the channel count above any module's
initial channel count, the system ignores the added channels.
Manually Downloading the Firmware
SR140 Software
Brooktrout boards in T1 robbed-bit,
T1 or E1 ISDN
Analog and BRI boards and
TruFax® analog and BRI boards
Multi-span Series ISDN boards
(non-V.34)
TR1034 boards with V.34 fax and
T.38 fax
Multi-span TR1034 boards and
single-span PCIe T1/E1 TR1034
boards with V.34 and T.38 fax.
