Configure IP Stack Dialog
Box
Trace Connection Settings
Dialog Box
March 2013
When the Brooktrout Configuration Tool detects an IP-enabled
device for the first time, it displays the Configure IP Stack dialog box:
Choose the IP stack you want to configure:
None: IP stack not installed
SIP: SIP stack installed (default)
H.323: H.323 stack installed
Both (SIP and H.323): Both SIP and H.323 stacks installed.
(Not supported on SDK Versions 5.2.0 - 6.2.0).
When any option is selected, all previously added host modules are
removed.
The settings for the IP stack can also be made in the settings.cfg file,
see Example of settings.cfg File on page
You use the Trace Connection Setting dialog to configure the
connection parameters for the Brktcctrace (server) application, and
your end user application (client). See the Debugging chapter in your
Dialogic® Brooktrout® Fax Products SDK Developer Guide for
details about the Brktcctrace application.
Server Port:
First Client Port:
Number of Client Ports:
Running the Dialogic® Brooktrout® Configuration Tool
127.
Specifies the server port number.
Specifies the client port that the server
will first try to connect to.
Specifies the maximum number of
clients.
