Setting of nosepiece equipment
Press one of the two OBJECTIVE keys.
Change to nosepiece programming is made, and SET Objective is displayed in the upper line of the LCD
display. The set nosepiece position, the magnification and the contrasting technique of the objective are
displayed in the lower LCD line.
Activation of the toggle switch on the front of the stand permits a list of objectives to be scrolled
through upwards or downwards.
If the correct objective for the relevant nosepiece position appears in the LCD display, the next
nosepiece position can be swung in by pressing one of the two OBJECTIVE keys and the relevant
objective can be assigned.
Repeat the procedure for all nosepiece positions. Then change to the next programming item or exit
the Set mode.
Setting of reflector turret equipment
Press one of the two REFLECTOR keys.
Change to reflector turret programming is made, and SET Reflector is displayed in the upper line of the
LCD display. The set reflector turret position and the selected filter set are shown in the lower LCD line.
Activation of the toggle switch on the front of the stand permits a list of filter sets to be scrolled
through upwards or downwards.
If the correct filter set for the relevant reflector turret position appears in the LCD display, the next
turret position can be swung in by pressing one of the two REFLECTOR keys and the relevant filter
set can be assigned.
Repeat the procedure for all reflector turret positions. Then change to the next programming item or
exit the Set mode.
