Axiovert 200
1.7

Specimen stages and mounting frames

The Axiovert 200 microscopes can be equipped with the following specimen stages and mounting
frames:
Description
Specimen stage 250x230 mm with ceramic surface and
3-point support
Object guide 130x85 right, can be attached on both
sides, accepts various mounting frames
Object guide 130x85 left, can be attached on both sides,
accepts various mounting frames
Mechanical stage 130x85 R/L
Mounting frame for object guide (M)
Mounting frame for mechanical stage (K)
Gliding stage Z
Scanning stage
1.8

Binocular tubes

The following tubes can be used with the Axiovert 200 microscopes:
Description
Binocular tube 45°/23
Binocular phototube 45°/23,
with Bertrand lens and shutter
Binocular ergotube 25°/23
vertically variable,
with Bertrand lens and shutter
B 40-080 e 03/01
INSTRUMENT DESCRIPTION
Specimen stages and mounting frames / Binocular tubes
Cat. No.
000000-1005-827
000000-1005-828
000000-1005-829
Cat. No.
000000-1005-832
000000-1005-833
000000-1110-991
000000-1005-834
see price list
see price list
471722-0000-000
000000-1113-509
VIEWING ANGLE Light distribution in
/ %
FIELD
NUMB
ER
45° / 23 100 %
45° / 23 100-0, 0-100, 50-50
25° / 23 100 %
Carl Zeiss
1-13
