Axiovert 200
LEFT / RIGHT key for the motorized switching of the Sideport turret (3-13/13)
Key to switch the beam splitting ratio for Sideport (doc) right, Sideport (doc) left and VIS (visual
observation through the binocular).
Five motorized configurations are possible:
LSM connector SP L and Sideport 60 R
LSM connector BP and Sideport 60 L
LSM connector BP and FCS connector SPL
Safety device LSM / PASCAL
Change to beam path mot. LSM
Key pressed briefly:
key pressed again:
The set beam path is displayed depending on the VIS / Frontport / Baseport setting, i.e. the actual
intensities at the ports are displayed (in %).
Key for the motorized switching of the VIS / Frontport / Baseport slider (3-13/14)
Key to switch the beam path between Frontport (FP), Baseport (BP) and VIS (visual observation
through the binocular).
The display in the LCD display depends on the position of the Sideport turret.
The following is displayed: Binocular, Baseport, Sideport
Empty positions are not approached or displayed unless a different setting has been made in the
AXIOSET software program.
FCT key (3-13/15)
The AXIOSET software program permits any required CAN/SUB components to be assigned to this
key.
Unless the key has been assigned otherwise, the instrument is brought to a basic position (Home or
Default position) after activation.
Basic position:
Optovar 1x (pos 1)
HAL = 3 V
SP 100 % VIS (pos 1)
BP 100 % VIS (pos 2)
condenser aperture fully opened
condenser turret BF (pos 1)
reflector turret on transmission
FL shutter closed
Key "Set LM" (3-13/18)
briefly pressed:
pressed long (> 2 s):
B 40-080 e 03/01
OPERATION
Axiovert 200 M
current position is shown in the LCD display for 4 s (or until the next press
of the key);
without LCD display, the position is approached immediately
target position is displayed and approached
Light Manager values are saved
activation of Set mode
Carl Zeiss
3-21
