Fig. 2-21 Axiovert 200 M (rear)
Fig. 2-22 Power supply ebq 100 dc
(rear)
2-18
START-UP

Connection to the line

2.8
Connect microscope socket (2-21/1) to the line
socket via a line cable. The microscope can be
connected to line voltage between 90 and 264
VAC, 50 - 60 Hz.
The microscope is equipped with a wide-area
power unit which automatically adapts to the
available line voltage. Voltage change is not
required.
The N HBO 103 illuminator (for epi-fluorescence) is
supplied via a separate power supply.
The power
connected to the line via the line socket
(2-22/1) (also see section 2.13.3, "Attachment
of illuminator N HBO 103").
The ebq 100 dc is equipped with a wide-area
power unit which automatically adapts to the
available line voltage. Voltage change is not
required.

Connection to the line

supply ebq 100 dc
B 40-080 e 03/01
Axiovert 200
must be
