Axiovert 200
Key to Fig. 3-1:
1 On / Off switch
2 Nosepiece
3 Compartment for analyzer slider (can be equipped from the right or left)
4 Drive controls for XY-movement of the mechanical stage
5 Sideport right
6 Setting wheel for Optovar turret (max. 3 positions)
7 Reflector turret
8 Focusing drive coarse / fine
9 FL key on / off for fluorescence shutter
10 HAL on / off switch
11 Toggle switch for illumination intensity
12 Frontport
13 Binocular tube
14 Binocular component of the tube
15 Setting ring of eyepiece
16 Eyepiece
17 Polarizer D with 2-position filter changer
18 Centering screw for condenser
19 LCD display
20 Adjusting lever of luminous-field diaphragm
21 Setting knob for vertical adjustment of condenser
22 Centering screw for condenser
23 Condenser
24 Microscope stage
25 HBO / XBO adjusting aid
26 Compartment for 3-position filter slider (dia. 25 mm)
27 Compartment for slider with iris stop as aperture diaphragm reflected light
28 Compartment for slider with iris stop as luminous-field diaphragm reflected light
29 Sideport left
30 Setting wheel for Sideport right / Sideport left / vis
31 Clamping screw for Frontport
32 Setting knob for Frontport / Baseport / vis
33 Stop for focusing drive
34 Baseport
35 Key "Set LM"
B 40-080 e 03/01
OPERATION
Axiovert 200 Carl Zeiss
3-5
