Technical Data - Zeiss Axiovert 200 Operating Manual

Axiovert 200
Line frequency ...................................................................................................................... 50 to 60 Hz
Power consumption with internal power units
Axiovert 200 ...........................................................................................................................235 VA
Axiovert 200 M .......................................................................................................................235 VA
and external power units
Power supply N XBO 75, 100 ... 240 V AC ...............................................................................130 VA
Power supply N HBO 100, 90 ... 240 V AC...............................................................................265 VA
Fuses in accordance with IEC 127
Axiovert 200
100 ... 240 V AC ....................................................................................T 4.0 A/H; 250 V; 5
Axiovert 200 M
100 ... 240 V AC ....................................................................................T 4.0 A/H; 250 V; 5
Light sources
HBO 50 W/AC mercury pressure short-arc lamp
Lamp voltage for lamp type L1 and L2 .................................................... L1: 39 ... 45 V/L2: 34 ... 39 V
Power ........................................................................................................................................50 W
Average life............................................................................................................................... 100 h
HBO 103 mercury vapor short-arc lamp.........................................................................................100 W
Opto-mechanical data
Stand with stage focusing ............................................................................ with coarse drive (5 mm/rot)
Objective change ................................................................................................via 6-position nosepiece
Objectives......................................................................................................with W 0.8" x 1/36"thread
Eyepieces .................................................................................................. with plug-in diameter 30 mm
and............................................................................................................................field number 23
B 40-080 e 03/01
INSTRUMENT DESCRIPTION

Technical Data

Carl Zeiss
20 mm
20 mm
and fine drive (0.1 mm /rot)
Fine scaling 1 µm/scale part
Overall lift approx. 10 mm
1-15
