Axiovert 200
Key to Fig. 3-13:
1 On / Off switch
2 Nosepiece (motorized)
3 Reflector turret (motorized)
4 OBJECTIVE keys (forward and backward)
5 REFLECTOR keys (forward and backward)
6 Focusing drive coarse / fine (motor-supported)
7 ZERO key
8 FOCUS keys (Work / Load)
9 HAL on / off key
10 FL key on / off (fluorescence shutter)
11 Toggle switch for illumination intensity and programming
12 1x OPTOVAR key (maximum of 3 positions)
13 Left / Right key for Sideport switching
14 Key for switching between visual observation, Frontport, Baseport
15 FCT key – programmable function key
16 Condenser (motorized)
17 LCD display
18 Key "Set LM"
19 RS 232 connector
20 CAN / SB connector (CAN-Bus, Sub-bus)
On / Off switch (3-13/1)
position 0 = instrument switched off
position I = instrument switched on, switch lights up
HAL key on/off (3-13/9)
Brief pressing switches the halogen illuminator on or off alternately.
When the unit is switched on again, the voltage present at the time of switching off is automatically
set again.
When the unit is switched on, the lower line of the LCD display shows the voltage in a scale and the
lamp voltage value (nominal value). When the unit is switched off, the message HAL OFF appears on
the LCD display.
Long pressing (> 1 s) automatically sets the brightness to 3200K for color photography.
Motorized focusing drive (3-13/6)
Focusing knob available on both sides of the instrument.
Coarse adjustment - big knob
Fine adjustment - small knob
