Zeiss Axiovert 200 Operating Manual page 4

Carl Zeiss
CHAPTER 2 START-UP.................................................................................................................. 2-5
2.1 Unpacking and installation of the microscope............................................................. 2-5
2.2 Attachment of binocular (photo) tube ......................................................................... 2-6
2.2.1 Inserting the eyepieces and the centering telescope.................................................... 2-6
2.2.2 Inserting the eyepiece reticle ....................................................................................... 2-7
2.3 Attachment of transmitted-light illumination ............................................................... 2-8
2.3.1 Attachment of carrier for transmitted-light illumination (100 W) .................................. 2-8
2.3.2 Attachment of carrier for transmitted-light illumination (30 W) .................................... 2-8
2.4 Screw in objectives ..................................................................................................... 2-9
2.5 Attachment of microscope stages ............................................................................. 2-10
2.5.1 Attachment of mechanical stage 130x85 R/L and mounting frame
for mechanical stage (K)............................................................................................ 2-10
2.5.2 Attachment of scanning stage................................................................................... 2-10
2.5.3 Attachment of specimen stage 250x230, object guide and mounting frame
for object guide (M) .................................................................................................. 2-11
2.5.4 Attachment of heating stage .................................................................................... 2-12
2.5.5 Attachment of gliding stage Z ................................................................................... 2-12
2.6 Attachment of condensers ........................................................................................ 2-13
2.6.1 Condensers for the Axiovert 200............................................................................... 2-13
2.6.2 Condensers from the Axioplan 2 imaging / Axioskop 2 product line ........................... 2-13
2.6.3 Changing the DIC prism in the condenser turret ........................................................ 2-14
2.7 Reflector turret ......................................................................................................... 2-15
2.7.1 Attachment of reflector turret................................................................................... 2-15
2.7.2 Equipment of reflector turret .................................................................................... 2-15
2.7.3 Changing the filter set in the FL reflector module ...................................................... 2-16
2.7.4 Changing the beam splitter in the FL reflector module ............................................... 2-16
2.8 Connection to the line .............................................................................................. 2-18
2.9 Interfaces of the Axiovert 200 M ............................................................................... 2-19
2.10 Switch microscope and ebq 100 dc power supply on and off..................................... 2-19
2.11 Equipotential bonding terminals ................................................................................ 2-19
2.12 HAL 100 halogen illuminator..................................................................................... 2-20
2.12.1 Change / attachment of the HAL 100 halogen lamp .................................................. 2-20
2.12.2 Coarse alignment of halogen illuminator ................................................................... 2-21
2.12.3 Attachment of halogen illuminator............................................................................ 2-21
2.12.4 Fine alignment of halogen illuminator ....................................................................... 2-22
0-4
INTRODUCTION
Contents Axiovert 200
page
B 40-080 e 03/01
