Axiovert 200
3.2.2

Switching on and basic settings on the Axiovert 200 M (motorized)

Switch on the microscope with the on/off switch on the right side.
The indicator light in the switch lights up.
Initialization of the instrument follows.
After initialization, the LCD display shows the positions of all the stand components cyclically. The display
remains visible until a key is pressed.
3.2.2.1 Configuration (Set mode)
The microscope must be configured after it has been switched on, i.e. the equipment of the nosepiece
and the reflector turret, the Z-focus factors and the parfocal offset of the objectives to each other must
be set. Setting is performed in the Set mode with the aid of the LCD display.
The microscope is already configured in the factory in accordance with the equipment ordered by the
customer.
When the equipment in the nosepiece and the reflector turret is changed, the configuration must be
updated accordingly.
Activation of Set mode
To activate the Set mode, keep the Set LM key (3-12/1) on the instrument rear pressed for approx. 2
seconds until a double beep is emitted.
The objective name (default) or the reflector name in the LCD display starts blinking.
If no adjustment is performed for more than 60 seconds, the Set mode is exited automatically.
B 40-080 e 03/01
OPERATION
Axiovert 200 M Carl Zeiss
3-23
