5
FUNCTIONS FOR RECEIVE
D Scope set mode (continued)
The signal level that reaches a peak color is set to
Grid 1 to Grid 8 for the waterfall display.
Higher signal levels are Red, Yellow, Green, Light-
blue, Blue and Black in order.
Select the sweeping speed for the ±2.5 kHz span se-
lection from SLOW, MID and FAST.
Select the sweeping speed for the ±5 kHz span se-
lection from SLOW, MID and FAST.
Select the sweeping speed for the ±10 kHz span se-
lection from SLOW, MID and FAST.
Select the sweeping speed for the ±25 kHz span se-
lection from SLOW, MID and FAST.
Select the sweeping speed for the ±50 kHz span se-
lection from SLOW, MID and FAST.
Select the sweeping speed for the ±100 kHz span se-
lection from SLOW, MID and FAST.
Select the sweeping speed for the ±250 kHz span se-
lection from SLOW, MID and FAST.
Set the scope edge frequencies for fixed mode scope
with below the 1.6 MHz band selection.
NOTE: The waveform may be displayed incorrectly
with the "FAST" setting.
NOTE: The waveform may be displayed incorrectly
with the "FAST" setting.
• Set the frequencies between 0.030 to 1.600 MHz
range in 1 kHz steps.
Up to 500 kHz band width can be specified, so ei-
ther edge frequency will be set to the difference
between higher and lower frequencies become 5
to 500 kHz automatically while setting another
edge frequency.
5-6
