D USB mouse operation

Mouse pointer
5-9
FUNCTIONS FOR RECEIVE
If you connect a USB mouse to the transceiver, a
mouse pointer appears on the spectrum scope screen.
Now, you can change the frequency by using the
mouse.
The mouse changes the frequency that the scope is
selected in either the Main or Sub band. Or while
holding down [XFC], it changes the transmit fre-
quency.
• Mouse operation on the Center mode
Button Operation
Click
Left
Drag
Right Click/Drag
• Mouse operation on the Fix mode
Button Operation
Click
Left
Drag
Right Click/Drag
Description
The frequency changes to
the clicking point and mouse
pointer move to the center of
the screen.
The frequency changes to
the clicking point and mouse
pointer move to the center
of the screen, and then the
frequency increases or de-
creases.
The Right button temporarily
changes the frequency.
While holding the button, same
action as the Left button, but
release it to return to the origi-
nal frequency.
Description
The frequency and marker
change to the clicking point.
The frequency and marker
change to the clicking point,
and then the frequency in-
creases or decreases.
The Right button temporarily
changes the frequency.
While holding the button, same
action as the Left button, but
release it to return to the origi-
nal frequency.
