SET MODE
■ ACC set mode
Selects the desired connector(s) for modulation input
when data 1 mode (D1) is in use.
Selects the desired connector(s) for modulation input
when data 2 mode (D2) is in use.
Selects the desired connector(s) for modulation input
when data 3 mode (D3) is in use.
(continued)
• MIC
• ACC-A
• ACC-B
• MIC,ACC-A
• MIC,ACC-B
• ACC-A,ACC–B
• MIC,ACC-A,ACC–B : Use the signals from [MIC],
• S/P DIF
• LAN
• MIC
• ACC-A
• ACC-B
• MIC,ACC-A
• MIC,ACC-B
• ACC-A,ACC–B
• MIC,ACC-A,ACC–B : Use the signals from [MIC],
• S/P DIF
• LAN
• MIC
• ACC-A
• ACC-B
• MIC,ACC-A
• MIC,ACC-B
• ACC-A,ACC–B
• MIC,ACC-A,ACC–B : Use the signals from [MIC],
• S/P DIF
• LAN
12-8
: Use the signals from [MIC].
: Use the signals from [ACC1–A]
(pin 4). (default
: Use the signals from [ACC1–B]
(pin 4).)
: Use the signals from [MIC]
and [ACC1–A] (pin 4).
: Use the signals from [MIC]
and [ACC1–B] (pin 4).
: Use the signals from [ACC1–A]
and [ACC1–B] (pin 4).
[ACC1–A] and [ACC1–B] (pin 4).
: Use the signals from [S/P DIF].
: Use the signals from [LAN].
: Use the signals from [MIC].
: Use the signals from [ACC1–A]
(pin 4).
: Use the signals from [ACC1–B]
(pin 4). (default)
: Use the signals from [MIC]
and [ACC1–A] (pin 4).
: Use the signals from [MIC]
and [ACC1–B] (pin 4).
: Use the signals from [ACC1–A]
and [ACC1–B] (pin 4).
[ACC1–A] and [ACC1–B] (pin 4).
: Use the signals from [S/P DIF].
: Use the signals from [LAN].
: Use the signals from [MIC].
: Use the signals from [ACC1–A]
(pin 4).
: Use the signals from [ACC1–B]
(pin 4).
: Use the signals from [MIC]
and [ACC1–A] (pin 4).
: Use the signals from [MIC]
and [ACC1–B] (pin 4).
: U s e
t h e
s i g n a l s
[ACC1–A] and [ACC1–B] (pin
4). (default)
[ACC1–A] and [ACC1–B] (pin 4).
: Use the signals from [S/P DIF].
: Use the signals from [LAN].
f r o m
