D PSK decode set mode (continued)
Selects the operating frequency display for time
stamp usage.
NOTE: The frequency won't be displayed when
"OFF" is selected in "PSK Time Stamp" as
below left.
Set the text color for received characters.
• The color is set in RGB format.
• The set color is indicated in the box beside the RGB scale.
Set the text color for transmitted characters.
• The color is set in RGB format.
• The set color is indicated in the box beside the RGB scale.
Set the text color for time stamp indication.
• The color is set in RGB format.
• The set color is indicated in the box beside the RGB scale.
Set the text color in the TX buffer screen.
• The color is set in RGB format.
• The set color is indicated in the box beside the RGB scale.
• ON
: Displays the operating frequency.
• OFF : No operating frequency display.
• Push [F-3•Ω ≈] to select R (Red), G (Green) and B (Blue),
and then rotate the main dial to set the ratio from 0 to 255.
• Push [F-3•Ω ≈] to select R (Red), G (Green) and B (Blue),
and then rotate the main dial to set the ratio from 0 to 255.
• Push [F-3•Ω ≈] to select R (Red), G (Green) and B (Blue),
and then rotate the main dial to set the ratio from 0 to 255.
• Push [F-3•Ω ≈] to select R (Red), G (Green) and B (Blue),
and then rotate the main dial to set the ratio from 0 to 255.
4-27
RECEIVE AND TRANSMIT
4
