Icom IC-7800 Instruction Manual page 204

14
CONTROL COMMAND
D Command table (continued)
Cmd. Sub Cmd. Data
1A 050056 00 or 01 Send/read synchronous pulse level
050057 00 or 01 Send/read opening message indica-
050058 see p. 14-11 Send/read opening message contents
050059 20000101
to
20991231
050060 0000 to
2359
050061 00 or 01 Send/read CLOCK2 function
050062 see p. 14-10 Send/read offset time for CLOCK2
050063 see p. 14-11 Send/read CLOCK2 name
050064 00 or 01 Send/read calibration marker
050065 00 or 01 Send/read confirmation beep
050066 00
01
02
03
050067 0050 to
0200
050068 0050 to
0200
050069 00 or 01 Send/read quick dualwatch function
050070 00 or 01 Send/read quick split set
050071 see p. 14-11 Send/read FM split offset –9.999 to
050072 see p. 14-11 Send/read FM split offset –9.999 to
050073 00 or 01 Send/read split lock set
050074 00 or 01 Send/read tuner auto start set
050075 00 or 01 Send/read PTT tune set
050076 00 or 01 Send/read transverter set
050077 see p. 14-11 Send/read transverter offset
050078 00 to 02 Send/read RTTY mark frequency
050079 00 to 02 Send/read RTTY shift width
050080 00 or 01 Send/read RTTY keying polarity
050081 00 to 02 Send/read PSK tone frequency
050082 00 or 01 Send/read speech language
050083 00 or 01 Send/read speech speed
050084 00 or 01 Send/read S-level speech
050085 00 or 01 Send/read speech with a mode switch
Description
setting (00=L, 01=H)
tion (00=OFF, 01=ON)
Send/read date
( 20000101=1st Jan. 2000 to
20991231=31st Dec. 2099)
Send/read time
(0000=00:00 to 2359=23:59)
(00=OFF, 01=ON)
(240001=–24:00 to 240000=+24:00)
(up to 3-character)
(00=OFF, 01=ON)
(00=OFF, 01=ON)
Band edge beep OFF
Band edge beep ON (Beep sounds
with a default amateur band)
Band edge beep with user setting ON
Band edge beep with user setting/TX
limit ON
Send/read main band's beep audio fre-
quency
(0050=500 Hz to 0200=2000 Hz)
Send/read sub band's beep audio fre-
quency
(0050=500 Hz to 0200=2000 Hz)
(00=OFF, 01=ON)
(00=OFF, 01=ON)
+9.999 MHz for HF
+9.999 MHz for 50 MHz
(00=OFF, 01=ON)
(00=OFF, 01=ON)
(00=OFF, 01=ON)
(00=OFF, 01=ON)
(00=1275 Hz, 01=1615 Hz, 02=2125 Hz)
(00=170 Hz, 01=200 Hz, 02=425 Hz)
(00=Normal, 01=Reverse)
( 00=1000 Hz, 01=1500 Hz,
02=2000 Hz)
(00=English, 01=Japanese)
(00=Slow, 01=Fast)
(00=OFF, 01=ON)
operation (00=OFF, 01=ON)
Cmd. Sub Cmd. Data
1A 050086 00 or 01 Send/read memo pad numbers
050087 00 or 01 Send/read main dial function
050088 00 to 02 Send/read main dial auto TS
050089 00 to 02 Send/read sub dial auto TS
050090 00 or 01 Send/read mic. up/down speed
050091 00 or 01 Send/read quick RIT/⊿TX clear func-
050092 00 to 02 Send/read SSB notch operation
050093 00 to 02 Send/read AM notch operation
050094 00 or 01 Send/read DIGI-SEL control function
050095 00 or 01 Send/read band indication for filter set
050096 00 or 01 Send/read SSB/CW synchronous tun-
050097 00 or 01 Send/read CW normal side set
050098 00 or 01 Send/read band setting for audio out-
050099 00 or 01 Send/read external keypad set for
050100 00 or 01 Send/read external keypad set for
00 or 01 Send/read CI-V transceive set
050101
050102 00 or 01 Send/read RS-232C function
050103 00 to 04 Send/read RS-232C decode speed
050104 00 to 10 Send/read keyboard type
050105 0010 to
0100
050106 00 to 31 Send/read keyboard repeat rate
050107
050108 01 to 30 Send/read subnet mask
050109 00 or 01 Send/read scope indication during TX
050110 00 or 01 Send/read scope max. hold
050111 00 to 02 Send/read scope center frequency
050112 see p. 14-11 Send/read waveform color for receiv-
14-6
Description
(00=5 ch, 01=10 ch)
(00=MAIN, 01=MAIN+SUB)
(00=OFF, 01=Low, 02=High)
(00=OFF, 01=Low, 02=High)
(00=Low, 01=High)
tion (00=OFF, 01=ON)
( 00=Auto, 01=Manual,
02=Auto/Manual)
( 00=Auto, 01=Manual,
02=Auto/Manual)
(00=DIGI-SEL, 01=APF)
screen (00=Fix, 01=Auto)
ing function (00=OFF, 01=ON)
(00=LSB, 01=USB)
put from mic. connector
(00=MAIN+SUB, 01=SUB)
voice memory (00=OFF, 01=ON)
keyer memory (00=OFF, 01=ON)
(00=OFF, 01=ON)
(00=CI-V, 01=Decode)
( 00=300, 01=1200, 02=4800,
03=9600, 04=19200)
( 00=English, 01=Japanese,
02=United Kingdom, 03=French,
04=French (Canadian), 05=German,
06=Portuguese, 07=Portuguese (Bra-
zilian), 08=Spanish, 09=Spanish
(Latin American), 10=Italian)
Send/read keyboard repeat delay
( 0010=100 msec., 0100=1000 msec.;
50 msec. steps)
(00=2.0 cps to 31=30.0 cps)
Send/read IP address set
( 0000000000000001=0.0.0.1 to 0255
025502550254=255.255.255.254)
(01=128.0.0.0 to 30=255.255.255.252)
(00=OFF, 01=ON)
(00=OFF, 01=ON)
set (00=Filter center, 01=Carrier point
center, 02=Carrier point center (Abs.
Freq.))
ing signal
