Chapter 7: Plug-in Controls
D-Control lets you assign, display and control plug-ins di-
rectly from the control surface in several ways.
D-Control provides dedicated Dynamics and EQ sections for
plug-ins that support Dynamics and EQ plug-in mapping.
These sections include encoders and switches that map to
standard controls for each plug-in type.
Plug-ins of all types can be focused across multiple D-Control
channels using Custom Fader Plug-ins mode. See "Custom
Fader Plug-In Mode" on page 153.
Plug-in Channel Formats
D-Control supports mono, stereo, multichannel and
multi-mono plug-in channel formats. Multi-mono plug-ins
comprise up to eight individual mono channels that can be
linked in any combination.
With D-Control, you can display, edit, and link specific chan-
nels of multi-mono Dynamics and EQ plug-ins directly from
the Channel Select switches in the corresponding section.

Assigning and Removing Plug-ins

You can make plug-in assignments directly from D-Control in
several ways. In Inserts mode, plug-ins can be added on an in-
sert-by-insert basis. In Assign Inserts mode you can assign
plug-ins to insert positions on multiple tracks.
To assign a plug-in in Inserts mode:
Press the Inserts switch to display inserts on the channel
1
where you want to assign the plug-in.
Do one of the following:
2
• If the insert location you want to use is empty, press the
corresponding encoder Select switch.
– or –
• If a plug-in is already present in the insert location you
want to use, press and hold the corresponding encoder
Select switch.
At the insert position where you want to make the assign-
3
ment, turn the encoder knob to select from the first level of
menu choices.
Press the encoder Select switch to move down and the By-
4
pass/Mute/Pre switch to move up through menu levels.
When the plug-in you want to assign is displayed, press the
5
encoder Select switch to confirm your selection.
To assign plug-ins to multiple tracks:
Press the Assign Inserts switch to enter Inserts Assign mode.
1
The first two send or insert positions will show on the encoder
displays by default.
At the insert position where you want to make the assign-
2
ment, turn the encoder knob to select from the first level of
menu choices.
Press the encoder Select switch to move down and the By-
3
pass/Mute/Pre switch to move up through menu levels.
When the plug-in you want to assign is displayed, press the
4
encoder Select switch to confirm your selection.
Repeat steps 2–4 to make additional insert assignments.
5
Press the flashing Assign switch to confirm the assignments
6
and exit Inserts Assign mode.
To remove a plug-in:
Press the Set to Default switch.
1
Press the encoder Select switch for each plug-in you want to
2
remove.
Press the flashing Set to Default switch to exit Set to Default
3
mode.
Chapter 7: Plug-in Controls 71
