Closing the Assign Matrix
To close the Assign Matrix, do any of the following:
Press the bottom encoder Select switch (when labeled
"Exit") in the Assign Matrix Navigation Area. This exits the As-
sign Matrix even when the Matrix is locked.
Hold Control (Windows) or Command (Mac) and press the
bottom encoder Select switch (when labeled "Back") in the As-
sign Matrix Navigation Area. This exits the Assign Matrix even
when the Matrix is locked.
Press the flashing Escape switch. This works only when the
Assign Matrix is not locked.
Assigning I/O Paths
To assign an I/O path:
Press and hold the Sends switch on the channel where you
1
want to assign the path. I/O paths are displayed on the chan-
nel encoders.
Press the encoder Select switch for the I/O path you want to
2
assign. The Assign Matrix opens, with the current path indi-
cated by yellow text and a lit Select switch.
If necessary, use the switches in the Assign Matrix Naviga-
3
tion area to locate the I/O path you want to assign.
Press the encoder Select switch for the I/O path you want to
4
assign.
To assign multiple output paths (audio or MIDI):
Follow the above procedures to use the Assign Matrix to as-
1
sign or change an output path assignment.
If you want to make multiple assignments, enable Assign
2
Lock mode by pressing the encoder Select switch labeled
"Lock" in the Assign Matrix Navigation area.
In the Assign Matrix Navigation area, press the B/M/P
3
switch labeled "+" (below the "Lock" encoder) to latch output
assignments.
If necessary, use the switches in the Assign Matrix Naviga-
4
tion area to locate the output path you want to assign.
Press the encoder Select switches for the additional output
5
paths you want to assign.
To remove an I/O path:
Press and hold the Sends switch on the channel where you
1
want to remove the path. I/O paths are displayed on the chan-
nel encoders.
Press the encoder Select switch for the I/O path you want to
2
remove. The Assign Matrix opens, with the current path indi-
cated by yellow text and a lit Select switch.
In the Assign Matrix Navigation area, press the encoder Se-
3
lect switch labeled "Back" on the bottom encoder until you
reach the top level of I/O paths, then press the encoder Select
switch that corresponds to "--" (No I/O) in the Assign Matrix
Select area.
Chapter 12: Assigning Inserts, Sends and I/O with the Assign Matrix 147
