DigiDesign D-Control Manual page 174

Surround Inputs
Surround Inputs
Signal Name
Surround Input 1 (L)
Surround Input 2 (Lc)
Surround Input 3 (C)
Surround Input 4 (Rc)
Surround Input 5 (R)
Surround Input 6 (Ls)
Surround Input 7 (Rs)
Surround Input 8 (LFE)
GND
SHIELD GND
Stereo Inputs
Stereo Inputs
Signal Name
Stereo Input 1 (Left)
Stereo Input 1 (Right)
Stereo Input 2 (Left)
Stereo Input 2 (Right)
Stereo Input 3 (Left)
Stereo Input 3 (Right)
Stereo Input 4 (Left)
Stereo Input 4 (Right)
GND
SHIELD GND
166 D-Control Guide
Hot (+) Cold (–) Ground (shield)
24 12 25
10 23 11
21 9 22
7 20 8
18 6 19
4 17 5
15 3 16
1 14 2
13
connector housing
Hot (+) Cold (–) Ground (shield)
24 12 25
10 23 11
21 9 22
7 20 8
18 6 19
4 17 5
15 3 16
1 14 2
13
connector housing
Cue Outputs
Cue Outputs
Signal Name Hot (+)
SLS Output (Left) 24
SLS Output (Right) 10
Cue Output 1 (Left) 21
Cue Output 1 (Right) 7
Cue Output 2 (Left) 18
Cue Output 2 (Right) 4
Cue Output 3 (Left) 15
Cue Output 3 (Right) 1
GND
SHIELD GND
Main Speaker Outputs
Main Speaker Outputs
Signal Name Hot (+)
Main 1 (L) 24
Main 2 (Lc) 10
Main 3 (C) 21
Main 4 (Rc) 7
Main 5 (R) 18
Main 6 (Ls) 4
Main 7 (Rs) 15
Main 8 (LFE) 1
GND
SHIELD GND
Cold (–) Ground (shield)
12 25
23 11
9 22
20 8
6 19
17 5
3 16
14 2
13
connector housing
Cold (–) Ground (shield)
12 25
23 11
9 22
20 8
6 19
17 5
3 16
14 2
13
connector housing
