Assign Matrix Multi-Assign Mode
(Sends and Outputs Only)
In normal operation, the Assign Matrix lets you make one as-
signment at a time, toggling the previous assignment off. You
can set the Assign Matrix to allow multiple output assign-
ments.
To set the Assign Matrix to allow multiple assignments:
Display an Insert, Send, or I/O assignment in the Assign Ma-
1
trix.
In the Assign Matrix Navigation area, press the B/M/P
2
switch labeled "+" (below the "Lock" encoder") to latch out-
put assignments.

Insert Assign Matrix

The Insert Assign Matrix lets you display, assign, change, and
remove inserts from a session. The Insert Assign Matrix shows
insert positions (A-J), Insert type (such as TDM, RTAS, HW In-
sert), plug-in categories (such as EQ or DYN), plug-in manu-
facturer, and insert or plug-in names in the Assign Matrix Se-
lect area.
Displaying Inserts
To display an Insert in the Assign Matrix:
Press the Inserts switch on the channel with the insert you
1
want to display. Insert positions are displayed on the channel
encoders.
Do one of the following at the Insert position you want to
2
display:
• If no insert is present at the Insert position, press the en-
coder Select switch.
– or –
• If an insert is already present at the Insert position, press
and hold the encoder Select switch.
The Assign Matrix opens, showing Insert positions in the top
5 encoders (in yellow) and the track name in the bottom en-
coder (in green) in the Menu Area. The encoder Select switch
lights for the Insert position that is currently displayed in the
Select Area.
If no insert is present at the Insert position, the Select Area
shows the top level Insert menu items (Insert types such as
TDM, RTAS, and HW Insert) along with any default or favor-
ites plug-ins on the top level.
If an insert is already present at the Insert position, the Se-
lect Area shows bottom level Insert menu items, with the cur-
rent insert indicated by yellow text and a lit Select switch.
142 D-Control Guide
To page through options in the Assign Matrix Select area:
Press the Select switch (marked "<") or BMP switch (marked
">") on the encoder labeled "PG" in the Assign Matrix Navi-
gation area. To page continuously, press and hold the
switches.
To scroll through options in the Assign Matrix Select area:
Turn the encoder knob labeled "PG" in the Assign Matrix
Navigation area.
To move down through Insert menu levels:
Press the encoder Select switch for a menu item in the As-
sign Matrix Select area.
To move up through Insert menu levels, do one of the following:
In the Assign Matrix Navigation area, press the bottom en-
coder Select switch (labeled "Back").
– or –
In the Assign Matrix Navigation area, press the encoder Se-
lect switch for a menu level (such as TDM, RTAS, or HW Insert)
on the top encoders, to return to that level.
To momentarily display the full name of a menu item or insert in
the encoder displays:
Touch the encoder knob for the item.
To open/close the window for an insert:
Hold Start (Windows) or Control (Mac) and press the en-
coder Select switch for the Insert position in the Assign Matrix
Menu area.
Changing Insert Display for a Track in the Assign
Matrix
To display a different Insert in the Assign Matrix by paging
through inserts:
In the Assign Matrix Menu Area, do one of the following to
1
toggle the Menu Area view between Inserts A-E and Inserts F-J:
• Press the lit Page Up or Page Down switch in the Assign
Matrix Menu area.
– or –
• Turn any encoder in the Assign Matrix Menu area.
Press the encoder Select switch for the Insert position you
2
want to display.
