1. Have the operator take the printer off-line.
2. Power off the printer.
3. Unplug the printer power cord from the customer's power outlet.

Inspect Mechanical Parts

Top Cover And Cabinet Doors
1. Inspect the top cover:
a. Open the top cover. On cabinet models, make sure the dashpot holds the cover up in the open position.
b. Make sure the window is not cracked or broken.
c. Make sure the seal around the top cover is not cracked or broken.
d. Make sure there are no exposed sharp edges.
e. Make sure the wireform paper guide assembly is undamaged.
f. Make sure the electrostatic discharge (ESD) fingers are not loose or damaged. Make sure they touch the contact strips
on the frame when the cover is closed.
g. Close the top cover. Make sure the operator panel is centered in the opening of the cover.
2. On cabinet models, inspect the front and rear cabinet doors:
a. Make sure the seals and magnetic strips are not loose or damaged.
b. Make sure the restraining cable is attached and unbroken.
c. Make sure there are no exposed sharp edges.
d. Open the rear cabinet door and inspect the lower rear paper path for the following:
Make sure the paper stacker tray assembly or optional power stacker is in place and undamaged.
Print Mechanism
1. Open the printer top cover.
2. Make sure the shuttle cover is correctly installed and undamaged. (See page 326.)
3. Make sure the paper guide assembly is correctly installed and undamaged. (See page 348.)
