Motor Assembly, Ribbon Drive

Motor Assembly, Ribbon Drive
Removal
1. Prepare the printer for maintenance (page 313).
2. Remove the ribbon. (Refer to the Setup Guide. )
3. Remove the screws and washers that secure the ribbon drive motor to the base casting at the lower right and upper left
corners of the motor (page 416, Figure 46).
4. Lift and rotate the ribbon drive motor until the motor cable is aligned with the slot on the base casting.
5. Disconnect the ribbon drive motor cable connector.
6. Lift the motor up and out of the base casting.
Installation
1. Reverse steps 2 through 8 of the removal procedure above.
NOTE: Install the the ribbon drive motor mounting screws at the right front and left rear corners.
2. Install the ribbon. (Refer to the User's Manual. )
3. Return the printer to normal operation (page 314).
