Operator Panel Message
143 SHUTL DRIVER FAILED *
SEE USERS MANUAL
Table 3. Message List
Explanation
Shuttle driver failed. The shuttle
driver circuit on the controller
board is drawing too much
current.
Corrective Action
1. Power off and unplug the printer. Remove the paper guide
assembly or top cover to gain access to the card cage. Make sure
the shuttle data and power cables are undamaged and have good
connections at the shuttle and the controller board.
2. Check the shuttle for electrical shorts (page 252).
3. Plug in the printer and power it on. If the message appears, the
controller board or microcode is suspect. Do the following:
4. Save the printer configuration values. (Refer to the User's
Manual .)
5. Clear NVRAM (page 237).
6. Download and install the latest code from IBM First (page 231).
7. Power on the printer in download mode and load flash memory
(page 238).
a. If you encounter loading problems, go to the appropriate error
code for resolution.
b. If you encounter the failure or message that brought you to
this procedure, replace the controller board (page 319). After
replacing the controller board, DO NOT make the printer
READY, but proceed immediately to the next step.
8. Download and install the latest code from IBM First (page 231).
9. Power on the printer in download mode and load flash memory
(page 238).
10. If you encounter the failure after replacing the controller board,
reinstall the original controller board and contact your DDS and
Second Level Support.
11. Power on the printer. If the message appears, replace the shuttle
frame assembly.
