IBM Infoprint 6500-v05 Maintenance Manual page 407

Chapter 6
Illustrated Parts Breakdown
(Figure 42)
Item
No.
1
2
3
4
5
6
7
8
Part No.
39U2494 Ribbon Mask/Hammer Bank Cover Assy, 500
39U2495 Ribbon Mask/Hammer Bank Cover Assy, 1000
39U2496 Ribbon Mask/Hammer Bank Cover Assy, 1500
39U2508 Ribbon Mask/Hammer Bank Cover Assy, 2000
39U2498 Shuttle Assembly, 05
39U2497 Shuttle Assembly, 05, Advance Exchange
39U2500 Shuttle Assembly, 10
39U2499 Shuttle Assembly, 10, Advance Exchange
39U2502 Shuttle Assembly, 15
39U2501 Shuttle Assembly, 15, Advance Exchange
39U2506 Shuttle Assembly, 20
39U2503 Shuttle Assembly, 20, Advance Exchange
54P1527 Hammer Spring Assembly, 05
54P1528 Hammer Spring Assembly, 10
54P1529 Hammer Spring Assembly, 15
75P2817 Hammer Spring Assembly, 20S
39U2548 Power Supply, PFC, 5/10
39U2528 Power Supply, PFC, 5/10, Advance Exchange
39U2547 Power Supply, PFC, 15
39U2527 Power Supply, PFC, 15, Advance Exchange
39U2549 Power Supply, PFC, 20
39U2529 Power Supply, PFC, 20, Advance Exchange
Ref P101 Cable Connector
Ref Cable Assy, AC-In, Power Supply
39U2546 Controller PCBA, (V5)
39U2556 Controller PCBA, (V5) Adv Exch
14H5288 Housing, Connector Kit (P106/P107)
14H5279 Hammer Bank Logic Cable Assembly
Description Notes
Model v05 and v5P
Model v10 and v1P
Model v15
Model v20
Model v05 and v5P
Model v05 and v5P
Model v10 and v1P
Model v10 and v1P
Model v15
Model v15
Model v20
Model v20
Model v05 and v5P
Model v10 and v1P
Model v15
Model v20
Model v05, v5P, v10, and v1P
Model v05, v5P, v10, and v1P
Model v15
Model v15
Model v20 (shown in Figure 42)
Model v20 (shown in Figure 42)
Part of item 3
Part of Field Kit AC Assy 14H5289
P106, Motor Sensor, Left
See also page 295.
