How To Identify The Printer - IBM Infoprint 6500-v05 Maintenance Manual

Model Number
6500-v05
6500-v5P
6500-v10
6500-v1P
6500-v15
6500-v20
* Lines Per Minute

How To Identify The Printer

The model number of the printer indicates the printer family, rated maximum print speed, and type of enclosure. (See Figure 3.)
Infoprint 6500 Printer Family
Figure 3. This figure shows how to interpret printer model numbers.
Table 1. The Infoprint 6500 Printer Family
Print Speed of
Enclosure
Draft Mode Text
500 LPM * Floor Cabinet
500 LPM Pedestal
1000 LPM Floor Cabinet
1000 LPM Pedestal
1500 LPM Floor Cabinet
2000 LPM Floor Cabinet
Speed Rating:
v05 = 500 LPM
v5P = 500 LPM
v10 = 1000 LPM
v1P = 1000 LPM
v15 = 1500 LPM
v20 = 2000 LPM
6500-v5P
How To Identify The Printer
Hammer Bank
28 Hammers
28 Hammers
60 Hammers
60 Hammers
102 Hammers
126 Hammers
Housing Code:
P = Pedestal Model
0 or 5 = Cabinet Model
30
