Hammer Spring Assembly
NOTE: The 6500-v15 hammer bank is shown here.
Although the number of hammer springs and
mounting screws varies among printer models,
removal and installation are the same for all
hammer spring assemblies.
A
A
Discard old screws.
Figure 16. This figure shows how to remove a hammer spring assembly from the hammer bank.
334
