Fan Assembly, Hammer Bank

Removal
1. Prepare the printer for maintenance (page 313).
2. Remove the ribbon. (Refer to the User's Manual .)
3. Remove the shuttle cover assembly (page 326).
4. Pedestal Model: Remove the top cover assembly (page 327).
5. Trace the hammer bank fan cable assembly back to the controller board connector J107, releasing it from all cable
constraints. (See the cable routing diagrams on page 282 and page 283.)
6. Disconnect connector P107 from the controller board and remove the fan connector (HBF) from the connector shell. (See
page 324.)
7. Remove the two screws securing the fan to the base casting. Angle the hammer bank fan assembly up and out of the base
casting and feed the motor wires and cable connector out from between the base casting and the base pan. (See Figure
46, page 416.)
Installation
ATTENTION
Install the fan so the label faces up. Air flow is UP.
NOTE: The hammer bank fan assembly is installed by angling it down and under the shuttle motor.
1. Feed the hammer bank fan cable connector (HBF) and motor wires between the fan well of the base casting and the base
pan. Reach up under the base casting and route the fan cable to the right and angle the hammer bank fan assembly under
the shuttle motor and down into the fan well. (See Figure 46, page 416.)
2. Route the fan motor wires as shown on page 282 and page 283, connect fan cable connector (HBF) to P107, then connect
P107 to J107 on the controller board. (See page 324.)
3. Install two screws in the locations shown in Figure 46 on page 416.
4. Pedestal Model: Install the top cover assembly (page 327).
5. Install the shuttle cover assembly (page 326).
6. Install the ribbon. (Refer to the User's Manual .)
7. Return the printer to normal operation (page 314).
