Operator Panel Message
123 PAP BUSY TOO LONG *
SEE USERS MANUAL
Table 3. Message List
Explanation
Paper busy too long. Firmware
error on the controller board.
Corrective Action
1. Cycle power. Run the print job again. If the message appears,
download the emulation software again.
2. Run the print job again. If the message appears, power off and
unplug the printer. Remove the paper guide assembly or pedestal
top cover. Make sure connectors P106 and P107 are fully seated
on the controller board.
3. Plug in the printer and power it on. Run the print job again. If the
message appears, power off and unplug the printer. Make sure
the MPU cable, the hammer bank logic cable, and the hammer
bank power cable are undamaged and have good connections.
Replace as necessary. (See the Cable Shorts Test on page 254.)
4. Check the shuttle for electrical shorts (page 252).
5. Plug in the printer and power it on. If the problem reappears, the
controller board or microcode is suspect. Do the following:
6. Save the printer configuration values. (Refer to the User's
Manual .)
7. Clear NVRAM (page 237).
8. Download and install the latest code from IBM First (page 231).
9. Power on the printer in download mode and load flash memory
(page 238).
a. If you encounter loading problems, go to the appropriate error
code for resolution.
b. If you encounter the failure or message that brought you to
this procedure, replace the controller board (page 319). After
replacing the controller board, DO NOT make the printer
READY, but proceed immediately to the next step.
10. Download and install the latest code from IBM First (page 231).
11. Power on the printer in download mode, and load flash memory
(page 238). If you encounter the failure after replacing the
controller board, reinstall the original controller board and contact
your DDS and Second Level Support.
Display Messages
