Slot
Guides
NOTE The drive may continue to spin for a short duration after you remove it from the system. It is
best to let the drive stop spinning before removal to avoid damaging the drive. Wait at least
30 seconds from the time the LED goes out until you move the drive any more.
4. To insert the new drive, extend the latching clips on the disk drive and align the rails on
the sides of the drive with the slot guides. The metal casing of the drive faces up.
5. Push the drive between the latching clips until it slides all the way into the slot and
firmly engages the connector.
6. Close the latching clips to lock the drive in the slot.
7. Restart the system and ensure the LED for the new disk drive lights and remains steady
green.
8. Label the new drive with the same ADP, CH, and ID numbers used on the replaced
drive.
Latches
