4. From inside the chassis, grasp the front of the tray and slide it out of the bay.
5. If you are installing a SCSI device, do both of the following (see Chapter 6,
"Peripherals," for details):
Set the SCSI ID on the new drive to an unused ID number.
Disable termination on the new drive.
6. If you are installing an IDE device, proceed to the next step.
7. Do one of the following:
If installing a standard disk drive, place the disk drive in the tray, align the
mounting holes, and install the four mounting screws. See the following figure.
If installing a 1.6-inch device, such as a tape drive or a CD writer, remove the
mounting guide from the drive tray and attach the guide to the right side of the
device. See the following figure.
If installing a Kingston removable disk drive module, do not use the mounting
guide.
Drive
Mounting Guide
37
Drive Tray
Access Hole (2)
