54
J11: MCBL319A, System Board Power Cable Pinout
Pin
Signal
1
+3.3V
2
+3.3V
3
Ground
4
+5V
5
Ground
6
+5V
7
Ground
J12: MCBL210A, Intruder Switch Pinout
Pin
Signal
1
Intruder Alert (chassis open)
2
Ground
J14: MCBL318A, System Board Power Cable Pinout
Pin
Signal
1
+3.3V
2
+3.3V
3
Ground
4
Ground
5
+5V
6
+5V
7
Ground
8
+5V
J16, J17: 550 Watt Power Supplies Pinout
Refer to "550 Watt Power Supplies (MPWS139)" for the pinout of these connectors. See the
table on page 62.
J20: MCBL206A, CD-ROM Drive and Floppy Disk Drive Pinout
Pin
Signal
1
+12V
2
Ground
Pin
Signal
8
Power Good
9
No connect
10
+ 12V
11
+3.3V
12
-12V
13
Ground
14
Remote On
Pin
Signal
9
Ground
10
5V AO
11
+5V
12
+3.3V
13
Ground
14
Ground
15
Ground
16
+5V
Wire Color
Pin
Yellow
3
Black
4
Pin
Signal
15
Ground
16
Ground
17
Ground
18
-5V
19
+5V
20
+5V
Pin
Signal
17
Ground
18
+5V
19
Ground
20
+5V
21
Ground
22
+5V
Signal
Wire Color
Ground
Black
VCC, +5v
Red
