Screws For Floppy Disk Drive
Screws For Lower Drive Tray
3. Slide the floppy drive and lower tray into the system. This allows the front panel to
clear the drives when removing it.
4. Remove two screws (one each side) securing front panel to the chassis.
Screw For Front Panel
(inside access hole)
21
