Specifications - Intergraph InterServe 800 System Reference Manual

93

Specifications

The following specifications apply to InterServe 800 systems.
Weight
140 lb (63.4 kg) with eight drives
Dimension (H x W x D)
26.5 in x 8.6 in x 30 in (67.3 cm x 21.8 cm x 76.2 cm)
Maintenance Clearance
Deskside: 12 inches (30.5 cm) front, 8 inches (20.3 cm) back
Rackmount: 36 inches (91.4 cm) front and back
Electrical (Domestic)
AC line voltage: 90-132 VAC
Frequency: 47-63 Hz
Phase: 1-phase
Rated receptacle current: 15-amp, 125V
Electrical (Non-domestic)
AC line voltage: 180-264 VAC
Frequency: 47-63 Hz
Phase: 1-phase
Rated receptacle current: 15-amp, 250V
Power Consumption (Dual 550 Watt power supplies)
892 Watt total (two supplies, based on 120 VAC, 60 Hz)
Power Consumption (Single 300 Watt power supply)
446 Watt (single supply, based on 120 VAC, 60 Hz)
Room Recommendations
Ambient temperature, operating: 50 to 80 F (10 to 26 C ).
Relative humidity, operating: 20 to 80% (non-condensing).
Environment Impact
Heat Dissipation: 1878 BTU/hour, 7.88 kcal/min
