Peripheral Device Locations

You can add optional mass storage devices to the internal and external drive bays. The
following shows peripheral device locations 1 through 12. Devices are installed in all
locations for illustration.
The floppy, EIDE CD-ROM, and system drives are standard; other devices are available as
options. Both JBOD and RAID start numbering drive bays from the bottom.
Location 12, Floppy Drive
Location 11, EIDE CD-ROM Drive
Location 10
Location 9
Location 8
Location 7
Location 6
Location 5
Location 4
Location 3
Location 2
Location 1, System Drive
