Feature
Power Supply
System Board
The following table lists the main chip components on the MSMT497A system board.
Component
System BIOS
Processor
Host-to-PCI Bridge
Sound Controller
Ethernet Controller
SCSI Controller
Combo Controller
PCI-to-ISA Bridge
EIDE Controller
Universal Serial Bus Ports
Sound Controller
The sound controller is the Crystal CS4237B. Integrated onto the system board, the
controller is a complete, fully-featured PC 97 compliant sound implementation. It has the
following specifications:
Feature
Audio Resolution
MIDI/UART Mode Compatibility
Bus Interface
Description
Two Universal Serial Bus (USB) Ports
One Fast-SCSI 3 (Ultra) Port (standard)
One Fast Wide SCSI 3 (Wide Ultra) Port (optional for JBOD or
external SCSI)
Ethernet Port (RJ45 connector)
Audio Ports: Microphone, Line In, Line Out
300 Watts, auto-ranging; 550 Watts, auto-ranging, hotswap
Description
American Megatrends BIOS 887xx.ROM
Intel Pentium II; 300 Mhz or 333MHz, SEC (Single Edge
Connector)
Intel 82443LX
Crystal CS4237B
Intel 82558 10/100BaseTX PCI
Symbios SYM53C876
Standard Microsystems FDC37C682
Intel PIIX4
Intel 82371AB PCI/IDE Xccelerator
Intel 82371AB PCI/IDE Xccelerator
Specification
16-bit
Roland MPU401
16-bit ISA
95
