Video; Network - Intergraph InterServe 80 SL System Setup

76

Video

System powered on, but screen remains blank:
Reason
Monitor not powered on.
Monitor power cord not connected.
Video cable not properly installed.
Graphics card not seated properly.
Selected resolution is not supported by the
monitor.
Improper video display driver installed.

Network

Cannot connect to other systems on LAN:
Reason
Ethernet cable disconnected.
Incorrect software configuration.
Cannot plot to network plotter on LAN:
Reason
Network cable disconnected.
Plotter not added to Print Manager on your
system.
Plot node does not recognize your system.
Solution
Turn on power to the monitor.
Connect monitor power cord to AC outlet
and monitor.
Ensure video cable is connected to monitor
and system video out connector.
Open the base unit and re-seat graphics card.
See the System Reference.
Select a supported resolution. See the
graphics card documentation and
. file for resolution details.
README TXT
See the graphics card documentation and
. file for instructions; install a
README TXT
valid driver.
Solution
Reconnect Ethernet cable and ensure proper
connection. If cable is properly connected,
notify your System Administrator.
Notify your System Administrator.
Solution
Reconnect network cable, ensure proper
connection.
Notify your System Administrator.
Notify your System Administrator.
